Lead- free Hot Air Reflow Oven - Morel F8

Warranty:6 months

Usage:FUJI SMT machine

Quality:100% Tested

Brand Name:Morel

Type:SMT machine parts

Condition:Original new

Model	Morel F8
Heating System	Number of heating zones	top 8/ bottom 8
	Number of cooling zones	2(top 1, bottom 1)
	Heating passage	3100mm
	Heating style	Hot air
	Cooling style	Forced air cooling
	Exhaust Volume	10m³/min * 2 vanes
Conveyor System	Max. Width of PCB	450mm
	Mesh belt width	500mm
	Conveyor Direction	L→R(option: R→L)
	Process Height	900±20mm
	Conveyor type	Mesh and chain
	Range of rail width	50-400mm
	Conveyor speed	0-1800mm/min
	Auto/manual Lubrication	Standard
	Fixed track	Front track fixed(option: rear track fixed)
	Product clearance	Top and bottom 25mm
Control system	Power supply	5 line 3 phase 380V 50/60HZ
	Total power	48KW
	Startup power	40KW
	Steady consumption	8KW
	Ramp up time	20 mins
	Temp. setting range	From room temp. To 300℃
	Temp. control method	PID close loop control & SSR driving
	Temp. control precision	±1℃
	Temp. deviation on PCB	±2℃
	Data storage	Process Data and status storage(80GB)
	Nozzle plate	Aluminum Alloy Plate
	Abnormal Alarm	Abnormal temperature (overtemp/low temperature)
	Board dropped alarm	Tower light: Amber-warming, Green-normal, Red-abnormal
General	Dimension(LWH)	500013201490mm
	Weight	2000kg
	Color	Computer gray
